NCA - Established in 1999, we are a professional supplier of automatic flexible bag production machines and nozzle sealing machines.

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 1

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 2

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 3

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 4

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 5

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW

Name: Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW
Uploaded: 2025-11-28T16:05:12+08:00
Description: This machine is used to make packaging bags of various laminated films.

Usage
1.This machine is used to make packaging bags of various laminated films.
2.Through the optional auxiliary device, it can be widely suitable for making three-side seal bag, stand-up pouch three-side bag with pressed handle or soft handle automatically for rice and flour etc.

Inquiry

Write a Review

Advantage

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 6 Applicable bag type: 5 kg / 10 kg

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 7 Speed: 40pcs / min

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 8 Automatic hole punching, handle pressing and bag making in-line , save labor costs.

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 9 The sealing quality is smooth and beautiful.

List of Key Components

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 11 PLC control module: Panasonic Japan

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 12 Servo motor: Panasonic Japan

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 13 Film unwinding constant tension, AUTO rectifying

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 14 Speed reducer: Planetary China

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 15 Photoelectric: Datalogic Italy

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 16 Cylinder: AirTAC China

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 17 10.4’ touch screen: WEINVIEW, Taiwan

Three-side Seal Bag Making And Handle Pressing Machine NCA600SKW 18 Machine control system: Hangzhou Sotry, China

Main Technical Specification

Film material	BOPP、CPP、PET、PE、NYLON etc. Various laminated films.
Capacity	Three side seal bag:80-150parts/min Stand up bag: 90parts/min Three-side seal with handle bag: 35-40parts/min
Max film reel unwinding speed	45m/min (Machine designing speed)
Bag making error	length and width : ±1mm.
(Actual capacity is according to the bag length, film material and hot sealing efficiency.)
Film reel size	Main film:Max φ800×1220mm(width), inner hole: 3′
	Gusset film: Max φ600×150mm, inner, hole: 3′ air shaft
Pouch size	Bag length: Max600mm Bag width: Max420mm, (over 420 mm need the multiple conveying).
Total power	About 50KW
Power voltage	AC Three phase 380V，50HZ
Air pressure	0.5-0.7Mpa
Cooling water	10L/min
Machine working table height	950mm
	handle operation height 850mm
Machine dimension(MAX)	L×W×H: 18500mm×3500mm×2200mm
Machine weight	about 7000KG
Machine color	Gray (wallboard)/ stainless steel (guard board)

Product display

A1 (1) 拷贝 (4)

A1 (10) 拷贝

A1 (46) 拷贝

产品图拷贝 (8)

样品图拷贝 (8)
